Drip Pot Enclosures
Reduce energy consumption while efficiently and safely keeping your assets warm.
The model 26-1040 provides preheated instrument gas for applications such as motor valves and pilot operated regulators, where freezing can develop. In the 26-1040, high pressure gas is heated as it passes sequentially through a Kimray 2000 psi drip pot, a Meco high pressure regulator and a Fisher 67 supply gas regulator. The drip pot and the high pressure Meco regulator are enclosed in a stainlesssteel case and are heated by a 1500 btu catalytic heater. The package includes a Fisher 912 regulator to provide fuel gas for the catalytic heater.
Drip Pot Enclosures
The table below shows options included with our most popular configurations, but Catco is always happy to configure a unit to your exact specifications. Just contact us and we will be glad to help.
| Model Number | Pipe Size | BTU/hr | Length | Weight |
|---|---|---|---|---|
| 70-044 | 1″ to 4″ | 3000 or 6000 | 14″ | 18 lbs |
| 70-045 | 1″ to 4″ | 6000 or 12,000 | 26″ | 24 lbs |
| 70-502 | 1″ to 6″ | 24,000 | 26″ | 70 lbs |
5000 Series Single and Dual Coil Preheaters
All of our 5000 series come with optional thermocouples and shutoff valves.
Unsure what product is right for you? Need a custom solution that fits your unique operation? Call us at 972-563-8065 or request a quote today!
